STELCOR DDM (Drilled in Displacement Micropiles)

No Pounding. No vibrations. No spoils.

STELC  ADVANTAGES

STELCOR DDM (Drilled in Displacement Micropiles)
STELCOR Drilled-In Displacement Micropiles are deep foundation piles that can be installed quickly and support loads of over 200 tons. These piles are excellent because as they are screwed into the ground, there is a constant flow of grout at the top of the pile. This allows the grout to fill the pile and create a solid core, as well as interweaving the grout into the soil surrounding the pile and giving it even placement.

STELCOR micropiles have many advantages, such as no spoils, removal costs, environmental concerns, and noise or vibrations with install. These piles can also be installed in high water tables due to their penetrating grout placement. CMI is a certified installer of STELCOR micropiles, and provides many STELCOR solutions that are cost-effective and efficient.

Loads of up to 200 Tons

STELCOR certified installer badge
STELCOR Mircopile annotated structure diagram

SECONDARY GROUT COLUMN

UNIQUE CORRUGATED WEAVE OF GROUT INTO SURROUNDING SOILS

HIGH STRENGTH SOLID GROUT CORE

80 KSI STEEL CORE

SOIL DISPLACEMENT HEAD

GREATER LOADS IN LESS DEPTH.
